Snow Blower Motor with Hex Output

am-2235a

1 - 39 units: $36.00

40 - 99 units: $32.40

100 - 299 units: $28.80

300 - 999 units: $27.00

1000 - 4999 units: $25.20

5000 or more units: $23.40

Everyone's favorite motor for indexing, and small jobs in tight spaces, is back with everyone's favorite shaft, 1/2 in. hex! This motor and gearbox combo originally came from a snowblower assembly,...Read More

View Full Details

Product Overview

Everyone's favorite motor for indexing, and small jobs in tight spaces, is back with everyone's favorite shaft, 1/2 in. hex!
This motor and gearbox combo originally came from a snowblower assembly, but now has a custom shaft just for FRC. Use our half inch hex hub or a 1/2 in. hex bore wheel to transfer power directly, or sprocket and chain to drive the mechanism of your dreams! The shaft also now has a #10-32 hole in the end for easy hub/sprocket retention.

Specifications

  • Free Current: 5A
  • Maximum Power: 20 Watts
  • Mounting Hole Size: 10-32
  • No Load RPM: 100 RPM
  • Stall Current: 24A
  • Stall Torque: 70 in-lb
  • Voltage: 12 Volts
  • Weight: 1.1 lbs

5 reviews

  1. star star star star star 5.0 out of 5 stars

    Turret

    I used the motor to drive a turret. It works perfect. The shaft was a little long so I cut it to size. Highly recommend.

    ge from OCEAN ISLE BEACH

    Verified Purchaser

  2. star star star star star 5.0 out of 5 stars

    Good motor

    Great motor for turrets and low speed applications, especially where you don't want the motor to backdrive. Also, it is a pretty compact package that isn't super heavy for a motor/gearbox combo.

    GW from KANSAS CITY

    Verified Purchaser

  3. star star star star star 5.0 out of 5 stars

    Great Value

    With the 1/2 hex output shaft, this a very useful motor/gearbox system for FRC applications.

    JW from PALMYRA

    Verified Purchaser

  4. star star star star star 5.0 out of 5 stars

    Easy to get along with

    Initially we picked up a couple just to play with it without high hopes. This thing is not fast by any means, but man is it a convenient package. We're using it to index game pieces that have already been picked up. Mounted right to the shaft, we are able to locate this near the edge of our frame where a bag motor and gearbox would have stuck out. Now that is has the hex shaft, I could see us using this down the road a lot.

    TF from SOUTH SAINT PAUL

    Verified Purchaser

  5. star star star star star 5.0 out of 5 stars

    Not for contact

    This gearbox has a steel worm and a plastic main gear. Worm drives are great because they don't back drive but because of that, if you crank on the output, the worm can strip the main gear. So think hard before using this on anything that goes outside the robot.

    ML from EWING

    Verified Purchaser
