48 Tooth 20 DP 0.5 in. Hex Bore Aluminum Gear

This is the 48 Tooth Gear that can be used in place of am-0885.

0 reviews

View Full Details

Product Overview

This is the 48 Tooth Gear that can be used in place of am-0885.

Specifications

Bore: 0.5 in. Hex
Diametral Pitch: 20
Material: 6061 Aluminum
Pitch Diameter: 2.4 in.
Pressure Angle: 14.5 Degrees
Product Lifecycle: discontinued, check out <a href='/products/48-tooth-20-dp-0-5-in-hex-bore-aluminum-gear-for-swerve-steer'>am-4056</a> which is similar.
Teeth: 48
Thickness: 0.4 in.
Weight: 0.25 lbs

Documents

Layout Print(s)

am-2036 48 Tooth Aluminum Gear with 500 Hex Bore.PDF

CAD File(s)

am-2036 48 Tooth Aluminum Gear with 500 Hex Bore.STEP
