2013 C-Base FRC Drive Chassis w/ #35 Chain and Sprockets

am-2494

$579.00

This is a chain-driven version of the entire C-Base Chassis Kit distributed in the 2013 FRC team kit, all of the items AndyMark put into the FIRST FRC kit except for the Battery Plugs (am-0122), 90...Read More

0 reviews

Write a Review

Product Overview

This is a chain-driven version of the entire C-Base Chassis Kit distributed in the 2013 FRC team kit, all of the items AndyMark put into the FIRST FRC kit except for the Battery Plugs (am-0122), 9015 Motor (am-0912), and PG71 Gearmotor (am-2971).

(chains are not shown in the picture above)

This un-assembled kit includes the 6" HiGrip FIRST Wheel wheels and two Toughbox Mini gearboxes with flat mount plates. The 30" C-Base chassis is used as the foundation of this robot drivetrain.

The power transmission system for this chassis is using #35 roller chain and aluminum plate sprockets.

This Chassis Kit can be configured in a long, 6-wheel setup or a wide, 4-wheel setup.

Included Hardware:

Specifications

  • Drive Sprocket: 22 tooth
  • Driven Sprockets: 24 tooth
  • Length: Variable in 1" increments, with 32.25" maximum
  • Load Capacity: 600 lbs based on wheels
  • Motors: 2 CIM motors
  • Power Transmission Method: #35 roller chain
  • Top Speed: 9.6 feet/sec (approximate), with 150 lbs total robot weight
  • Weight: 28 lbs
  • Width: Variable in 1" increments, with 32.25" maximum
