Product Overview:
Pixy CMUcam5 Image Sensor is a fast vision sensor you can quickly "teach" to find objects. It connects directly to Arduino and other controllers. Pixy pairs a powerful dedicated processor and image sensor. Pixy processes images from the image sensor and only sends the useful information (e.g. purple dinosaur detected at x=54, y=103) to your microcontroller. The information is available through one of several interfaces: UART serial, SPI, I2C, USB, or digital/analog output so your Arduino or other microcontroller can talk easily with Pixy and still have plenty of CPU available for other tasks.

For more information visit, http://cmucam.org/projects/cmucam5

  • Height of Camera: 25mm / 1"
  • Front two screw holes: 19mm apart / 0.75"
  • Back two screw holes: 47mm apart / 1.85"
  • Weight (no IDC cable, no screws): 25.5g
  • Processor: NXP LPC4330, 204 MHz, dual core
  • Image sensor: Omnivision OV9715, 1/4", 1280x800
  • Lens field-of-view: 75 degrees horizontal, 47 degrees vertical
  • Data outputs: UART serial, SPI, I2C, USB, digital, analog
